Technical specifications
Drawing
Table
CODE SIZE DN MASTER BOX L1 L2 Z1 Z2
ZC0130012012012 12 12 100 29 30 11 12
ZC0130015015015 15 15 100 41 42 19 20
ZC0130018018018 18 18 50 46 56 23 33
ZC0130022022022 22 22 40 49 54 25 30
ZC0130028028028 28 28 30 58 58 33 33
ZC0130035035035 35 35 20 58 62 32 36
ZC0130042042042 42 42 10 71 75 35 39
ZC0130054054054 54 54 10 82 86 42 46
Notes
The big-size, item AC0130, is available. See at page 156
Applications
BIM
ZC0130.rfa
