Technical specifications
Drawing
Table
D BAG MASTER BOX CODE A S1 S2 Z
15 10 100 QM8340015015000 85 24 25 45
18 10 100 QM8340018018000 95 30 30 55
22 5 40 QM8340022022000 97 37 34 51
28 5 30 QM8340028028000 91 46 45 45
35 5 20 QM8340035035000 120 52 50 68
42 1 10 QM8340042042000 134 64 60 74
54 1 8 QM8340054054000 144 85 75 74
Applications
