Technical specifications
Drawing
Table
CODE SIZE DN MASTER BOX L1 L2
RS9271012012000 12 12 150 58 18
RS9271015015000 15 15 100 82 22
RS9271018018000 18 18 100 92 23
RS9271022022000 22 22 60 97 24
RS9271028028000 28 28 40 107 25
RS9271035035000 35 35 30 114 26
RS9271042042000 42 42 15 142 41
RS9271054054000 54 54 10 163 45
Notes

For dimensions > 54 mm, item RR9271 is available. Water use only.

Applications
