Technical specifications
Drawing
Table
CODE SIZE MASTER BOX G D L1 S Z
RZ8359018B01000 1x18 100 1 18 33 37 10
RZ8359022A34000 3/4x22 80 3 22 46 30 22
RZ8359022B01000 1x22 100 1 22 38 37 14
RZ8359028B12000 1.1/2x28 30 1 28 34 52 9
RZ8359035C02000 2x35 20 2 35 34 64 8
RZ8359042C02000 2x42 20 2 42 48 64 12
RZ8359A12012000 1/2x12 150 1 12 30 24 12
RZ8359A12014000 1/2x14 100 1 14 31 24 9
RZ8359A12015000 1/2x15 100 1 15 44 24 22
RZ8359A12016000 1/2x16 100 1 16 44 24 22
RZ8359A34012000 3/4x12 100 3 12 25 30 7
RZ8359A34014000 3/4x14 150 3 14 29 30 7
RZ8359A34015000 3/4x15 150 3 15 29 30 7
RZ8359A34016000 3/4x16 100 3 16 32 30 10
RZ8359A34018000 3/4x18 70 3 18 32 30 9
RZ8359A38012000 3/8x12 150 3 12 40 20 18
RZ8359A38014000 3/8x14 100 3 14 43 20 21
RZ8359B14028000 1.1/4x28 50 1 28 34 46 9
Applications
