Specifiche tecniche
Disegno
Tabella
R X D BAG MASTER BOX CODICE L S Z
1/2" x 12 10 100 ZCF243A12012000 38 19 20
1/2" x 15 10 150 ZCF243A12015000 43 25 21
1/2" x 18 10 150 ZCF243A12018000 44 27 21
1/2" x 22 10 100 ZCF243A12022000 45 32 21
3/4" x 18 10 100 ZCF243A34018000 45 27 22
3/4" x 22 10 100 ZCF243A34022000 46 32 22
3/4" x 28 5 70 ZCF243A34028000 57 32 32
3/8" x 12 10 100 ZCF243A38012000 34 19 16
3/8" x 15 10 100 ZCF243A38015000 39 25 17
1" x 22 5 50 ZCF243B01022000 55 34 31
1" x 28 5 50 ZCF243B01028000 57 34 32
1" x 35 5 40 ZCF243B01035000 60 38 34
1"1/2 x 35 5 20 ZCF243B12035000 62 48 36
1"1/2 x 42 5 20 ZCF243B12042000 72 50 36
1"1/4 x 35 5 40 ZCF243B14035000 60 42 34
2" x 54 1 10 ZCF243C02054000 83 60 43
Note
The big-size, item ACF243 is available. See at page 161
Applicazioni
Video e media disponibili
BIM
ZCF243.rfa
